HQT MID-END ANALOG SERIES TH-2800

HQT TH-2800 is a professional two-way radio with fashionable design, multiple functions, stable performance and wide frequency range. It is one of the most cost-effective models and a convenient communication equipment for users who work in hotels and entertainment places and those who are engaged in property and security managements.
  • Scan;
  • VOX;
  • Monitor;
  • Voice Prompts;
  • CTCSS/CDCSS;
  • Battery Power Indication;
  • Squelch Tail Elimination;
  • Busy Channel Lockout (BCL).
TI OMAP SERIES is recommended for customized needs and requirements.

Please contact our sales consultants for more product information. Get Support >>

Voice Prompts
This function is designed for users working in dark environment, it enables radio to report current channel when the corresponding function key is pressed.
Monitor
This feature enables user to hear weak signals. User can adjust volume by pressing MONI key when no signals are received.
Battery Power Indication
The radio will report current battery power when the corresponding function key is pressed. It also reminds users to replace or charge the battery if the battery power is low.
High/Low Power Switch
The radio can be switched between low power and high power. To save power, users can switch it to low power mode when talk distance is short.
VOX
Hands-free operation is available when VOX function is turned ON.
PTT ID Encode (DTMF)
TH-2800 provides identification of radio to control center or partners through this function. It simplifies the way of communication and management.
Squelch Tail Elimination
The function will minimize the annoying audio outputs that occur at the receiver during a transmission.
Scan
This feature enables radio to scan every channel in scanning list when user presses corresponding function key to activate scanning. The user can detect the available channel of partners, and then start communicating.
Busy Channel Lockout (BCL)
BCL is used to protect the on-going conversation from unwanted interference. Users might also be blocked sometimes.
CTCSS/CDCSS
CTCSS/CDCSS encode and decode are useful to avoid unwanted conversation on the same channel.
25.0 kHz/20 kHz/ 12.5 kHz Switch
TH-2800 has different channel spacing 25.0 kHz/20 kHz/12.5 kHz, which are optional to comply with the regulations of different countries.
Wired Clone
To quickly set the parameters on a radio, users can clone the radio data from another radio with the supplied data cable, which can save the time of parameters setting.
PC Programming
Frequency and various features can be set by PC programming software.
General
Frequency Range VHF: 136-174MHz
UHF: 400-470MHz; 350-390MHz
U/V: 136-174MHz/400-470MHz
Channel Capacity 16 (15+S)
Channel Spacing 25.0kHz / 12.5kHz
Frequency Stability ±2.5ppm
Operating Temperature -25℃ ~ +55℃
Antenna Impedance 50Ω
Operating Voltage 7.5V
Dimensions (H×W×D) 105×60×35mm
Weight (With Antenna & Battery) 225g
Battery 1600mAh
Receiver
Sensitivity 0.20μV(25kHz) / 0.22μV(12.5kHz)
Adjacent Channel Selectivity 60dB@12.5kHz / 70dB@25kHz
Intermodulation Rejection 65dB
Spurious Response Rejection 70dB
S/N 40dB@12.5kHz / 45dB@25kHz
Rated Audio Power Output 700mW
Rated Audio Distortion ≤5%
Transmitter
RF Power (H/L) UHF High Power: 4W/ Low Power: 1W
VHF High Power: 5W/ Low Power: 1W
Modulation Type 16KΦF3E / 8KΦF3E
Modulation Limiting ≤2.5kHz @ 12.5kHz
5kHz @ 25kHz
FM Distortion ≤5%
Residual FM 40dB @ 12.5kHz / 45dB @25kHz
Adjacent Channel Power -60dB
Spurious and Harmonics ≤-36dBm(<1GHz)/-30dBm(>1GHz)

All specifications are tested according to applicable standards and subject to changes without notice due to continuous development.


Accessory List

Standard Accessories
Antenna Battery Charge Adapter Desktop Charger Belt Clip Hand Strap
Optional Accessories
Earphone Remote Microphone Programming Cable Leather Case
